Datalogic Matrix 410N
Description
Matrix 410N™ is an industrial 2D reader for tracking, material handling, and logistics. It is equipped with an ultra-fast image sensor, reading at 45fps with a resolution of 2.0MP.
Ethernet connectivity is built-in, including standard communication services: TCP/IP, HTTP, FTP, and other more widely used standards such as PROFINET IO, Ethernet/IP, MODBUS TCP…
It is flexible and easy to configure as a stand-alone reading device or as part of several devices connected in a digital chain.
Matrix 410N offers the possibility to save images that have been scanned for later review. The internal memory can store up to 3000 images or automatically transfer them to a client’s FTP server.
For more information, please refer to the attached .pdf files, and brochures.
Technical features
- Read codes: 2D
- Reading speed: 45 frames/sec.
- Light Source: LEDs
Connection
- Ethernet
- RS232
- RS485 (IBM 46xx)
- Profinet
- Internal memory: Yes
Environment
- Operating temperature: 0°C – 50°C
- Relative humidity: 20% – 80%
Physical characteristics
- IP class: 67
- Sizes: 123 x 60,5 x 87mm
- Weight: 482g
