Newland NQuire1000 Manta
Description
Multifunctional business class micro-kiosk. Communicate with your target audience through self-service or use Manta as a low-cost Android POS system daily. This multifunctional device is easy to install and use anywhere. The solution will be perfect for installation on shelves or counters in supermarkets, grocery stores, pharmacies and many other places of sale. Thanks to the wide range of functions and various accessories, Manta is perfectly adaptable to different purposes of use and provides a self-service solution according to your needs.
A fully functional CMS system
- With Quad Core Cortex A9 processor up to 1.6 GHz.
Simple installation and high mobility
- The solution will be perfect for installation on shelves or counters in supermarkets, grocery stores, pharmacies and many other places of sale.
Fast action
- It is equipped with a Newland EM2037 2D barcode scanner.
Extensive customisation options and a range of features
- External SCR, thermal printer, WiFi, Bluetooth, POE and other communication solutions.
Apps according to needs
- Thanks to the Android 5.1 operating system, you have the opportunity to quickly and simply create the apps you need.
Wide installation options
- Folding stand, VESA magnetic shelf stand, VESA wall mount.
Technical features
| Technical specification | Processor: | RK3188T, Quad Core Cortax-A9; up to 1.6GHz, Mali-400 MP4 GPU, up to 600MHz | |
| Operating system: | Android 5.1 | ||
| Memory: | 2GB DDR3 / 8 GB eMMC / SD card slot | ||
| Barcode scanner | 1D barcodes | Code39, Codabar, Code128, Code93, EAN8, EAN13, MSI, UPC-A, UPC-E, Interleaved 2 of 5 and others |
|
| 2D barcodes | QR, PDF417, DataMatrix, MaxiCode and others | ||
Screen size
- 8”
Connection
- Wireless
- Bluetooth 4.0
Environment
| Operating temperature: | -20℃~50℃ |
| Storage temperature: | -30℃~70℃ |
| Humidity resistance: | 5%~95% (without condensation) |
| Shock resistance: | Fall from no 1.2m |
| IP class: | IP54 |
Physical characteristics
| Size: | 252(L) ×178(W) × 24(H) mm |
| Weight: | 594g (including battery) |
| Display: | 10.1” |
| Audio: | Microphone, 2 integrated speakers 1.5W |
| Power supply: | AC 100 ~ 240V, 50 ~ 60Hz, 2A Max, DC12V + 5% |
| Camera: | 5 MP, Autofocus |
| GPS: | Yes |
| LAN: | RJ45 Ethernet |
| WPAN: | Supported Bluetooth 4.0 |
Additional accessories
- NQuire1000 Manta – Folding table stand
- NQuire1000 Manta – VESA wall mount
- NQuire1000 Manta – VESA Magnetic Shelf Stand
- NQuire1000 Manta – Magnetic card reader
- NQuire1000 Manta – NFC card reader
